AM4117MZTL Dino-Lite EDGE PLUS Microscope 1,3 Mpx / FLC / LWD

799,00 € *

zzgl. MwSt. zzgl. Versandkosten

  • AM4117MZTL
Dino-Lite AM4117MZTL Dino-Lite EDGE PLUS Microscope 1,3 Mpx / FLC / LWD - 1.3 Megapixels:... mehr
Produktinformationen "AM4117MZTL Dino-Lite EDGE PLUS Microscope 1,3 Mpx / FLC / LWD"

Dino-Lite AM4117MZTL Dino-Lite EDGE PLUS Microscope 1,3 Mpx / FLC / LWD

- 1.3 Megapixels: Thanks to MJPEG compression, the advanced CMOS image sensor can transmit fluid and crisp images at 30 FPS with resolution up to 1280x960.
- ?Long Working Distance (LWD) optics: The LWD optics yield more working space between the object and the microscope, making it ideal for applications such as repairing or assembly.
- ?Flexible LED Control (FLC): Tasking with software, the FLC maximizes illumination flexibility by offering independent on/off control of the four LED quadrants in addition to the 6-levels intensity adjustment capability.
- ?Robust metallic housing: The metal housing made of anodized aluminum alloy offers compelling advantages of protection and endurance. The anodized alloy provides extra protection from electromagnetic interferences.
- ?Adjustable polarizer: The built-in adjustable polarizer allows to remove freely the unwanted reflection or glare from the object surface for a better contrast.
- ?Scroll Lock: The scroll lock ensures the focus knob staying at the desired focus or magnification position without worry of unintentional movement.
- ?Interchangeable caps: The interchangeable caps provide adaptability to numerous applications with alternative lighting or object interface, such as but not limited to diffused-light, ring-light, and coaxial-light etc.

Technical data:
Dino-Lite Range: Dino-Lite Long Working Distance

Beleuchtung
Licht / LED Type:white
LEDs: 8 pcs.
LED on/off: yes
Infrared Filter: IR cut-filter >650nm
Diffuser: yes, (N3C-D included)
Emissionfilter: no
Polarisation: yes, linear

Optik
Magnification: 10-220x
Makrozoom: no
Working Distance: Long Working Distance
Lens Type: Glas with anti reflection coating

Sensor
Sensortype: CMOS
Resolution: 1,3 Megapixel (1280x1024 px)
MaximaleFramerate: 30 fps @ 1,3 Mpx

Compatibility
Conneftion: USB 2.0
Operating System: Windows XP, Vista, 7, 8, 10, MacOS 10.9 or higher)
Software included: DinoCapture 2.0(Windows); DinoXcope (Mac OS)
Picture Format (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2,JPC, PGX
Video Format (Windows): WMV, FLV, SWF
Picture Format (MacOS): PNG, JPEG
Video Format (MacOS): MOV
Picture Standard: DirectShow, UVC

Housing
Housing Material: Aluminium
Magnification Lock: yes
Dimensions: 10,5cm (L) x 3,2cm (D)
Weight: ~125g
Cabe length: 1,8m

Features
Special Features: FLC
Measuring Function: yes
Calibration: yes
Microtouch: yes
ESD save: yes

Others
Package Content: Microscope, Pouch, Software CD, Calibration Sheet, Caps (N3C-O; N3C-C; N3C-D; N3C; N3C-L; N3C-S)
Warranty: 2 years
Certification: CE, FCC, ROHS

Field-of-view
Field-of-view max: 39,0 x 31,2 @10x Magnification
Fiel-of-view min: 2,8 x 2,2mm @220x Magnification
